Papa Small P301 Nougat Candy Bar Cutting Machine / Mini Crunch Bar Making Machine

Minimum Order Quantity : 1 set Price : Negotiate
Packaging Details : Fumigation-free wooden box Delivery Time : 15-30 working days
Payment Terms : L/C, T/T, Western Union, MoneyGram Supply Ability : 2 sets/month
Place of Origin: CHINA Brand Name: iPAPA
Certification: CE Model Number: P301

Detail Information

Capacity: 100-250KG/H Power: 5kw
Weight: 1200KG Voltage: 380V, Three Phase
Dimention: 4800*920*1200mm Cooling Type: Cooling Fans
Material: Stainless Steel 304 Warranty: 1 Year
After-sales Service Provided: Engineers Available To Service Machinery Overseas Condition: New
Application: Granola Bars, Cereal Bars, Muesli Bars, Peanut Bars,rice Bars, Etc.
High Light:

Nougat Candy Bar Cutting Machine

,

Mini Crunch Bar Making Machine

,

P301 Bar Making Machine

Product Description

Papa small P301 nougat candy bar cutting machine/Mini crunch bar making machine



Description:



The small P301 nougat candy bar making machine is our small designed machine according to customers’requirement of small size and low budget.The small cereal bar machine is very suitable for the customers who make the cereal bar based on cripsy rice, puffed rice, cereals, granolas, nuts, seeds, dry fruits, protein powder, grounded nut powders or energy elements,but the production demand is very small and the operation space is very small.

The small crunch bar cutting machine is composed of the feeding hopper, double rollers, cooling fans, cutting unit, conveyor and control box. Customers just need put the well-mixed ingredients in the hopper of the snack food bar machine,the two equalizing rollers can roll the mixture to a continuous salb and then cut it to desired product width.The small snack bar machine can be widely used on  producing cereal bar, muesli bar, granola bar, energy bar, nut bar, seed bar, protein bar, nutrition bar, rice bar, nougat candy bar, and so on. So the cereal bar machine is also a muesli bar making machine or granola bar making machine.





Papa Small P301 Nougat Candy Bar Cutting Machine / Mini Crunch Bar Making Machine 0



Specifications:



Model P301
Capacity 100-130 KG/H
Cooling type Cooling fans
Voltage 380V, three phase
Power 5kw
Dimension

2500*120*1200mm

Weight 450KG





P301 Automatic Snack  bar forming machine demo video:





Bars produced by P301 Slab bar forming machine:

Papa Small P301 Nougat Candy Bar Cutting Machine / Mini Crunch Bar Making Machine 1

Application:



New model slab bar making machine video:





Optional device:



1. Bar separating system

Bar separating system is used in the slab bar production line for bar separating from each other, so that each bar will has enough distance to be chocolate coated or packed by full automatic packaging line.



Papa Small P301 Nougat Candy Bar Cutting Machine / Mini Crunch Bar Making Machine 2





Papa Small P301 Nougat Candy Bar Cutting Machine / Mini Crunch Bar Making Machine 3



Cooling tunnel with bar separating system video:





2. Chocolate enrobing line

The Chocolate enrobing line is used after the slab bar line for chocolate coating outside the bar or on the bottom of the bar. The separated bars will be transfered to the chocolate enrober and the long cooling tunnel will cool down the chocolate bars before entering the flow wrapping machine.

Papa Small P301 Nougat Candy Bar Cutting Machine / Mini Crunch Bar Making Machine 4

Chocolate enrobing line for energy bar video:





3. Full automatic sorting and flow wrapping line

The full automatic sorting and flow wrapping line is used in the production lines like slab bar production line, protein bar production line or chocolate production line to do automatically bag flow wrap packaging. This section has no manual operation, all processes are done by the machine.

Papa Small P301 Nougat Candy Bar Cutting Machine / Mini Crunch Bar Making Machine 5

Bar sorting and flow wrappling line video:





Slab bar forming machine is the most mature product made by Papa Industrial, It has different names in different countries, it is often called cereal bar making machine and granola bar making machine in USA and European countries, It is often called peanut candy bar making machine in India, or sesame snaps making machine and muesli bar making machine in Middle East, etc. No matter it's a cereal bar prodction line, granola bar production line or energy bar production line, they are all slab bar forming line, only some parts of the slab bar line need to be customized.



Welcome to contact us if you are interested in our multifunctional energy bar making machine!
